Fat and butter melter
Melting blocks of butter, fats and coatings
⏱ Calculation and quotation within one business day
CE marking · ISO 9001 · export deliveries, commissioning. Terms →
PZh-400 fat melter for food productionSaint PetersburgDescription
A fat melter melts blocks of butter, animal and vegetable fats and fat-based coatings: the blocks are placed on a mesh frame above a heating coil, and the melt flows down into a receiving tank and is drained through a stainless steel valve. Heating is by steam or electric heating elements with temperature control, so the product does not burn. Volume is from 50 to 5,000 L; available to order are an agitator for the melt, a spray device that speeds up melting several times, and side or end loading.
It is used for melting blocks of butter, fat-based coatings and vegetable fats. It consists of a coil through which steam is passed, a mesh frame on which the fat blocks are placed, and a receiving tank. During melting, the molten product flows through the frame heated by the coil and runs down to the bottom of the tank, from where it is drained through a stainless steel valve.
The melter can be made to your dimensions and requirements, and for higher capacity.
Advantages:
- heating by steam or by electric heating elements; - an agitator for the molten fat can be installed at the bottom of the tank; - a spray device that sprays fat during melting (increases melting speed several times); - side/end loading design; - thermal insulation; - attractive appearance; - fat melter volume from 50 to 5,000 L
To find out more and buy a fat melter, please fill in the form below:
Price from €3,400. The final cost depends on the configuration, technical specifications and the tasks the equipment is selected for: volume and capacity, heating type, level of automation and options. Write or call us — our process engineer will select a suitable option and prepare a quotation within one business day.
Specifications
| Volume | from 50 to 5,000 L |
| Heating | steam / electric heating elements |
| Products | butter blocks, animal and vegetable fats, coatings |
| To order | agitator, spray device, side or end loading |
FAQ
What fat melter volumes are available?
From 50 to 5,000 L, and to order to your dimensions and capacity.
How is the fat melter heated?
By steam or electric heating elements. It can be supplied without an automation cabinet, in which case the heating elements are set to a fixed temperature.
How can melting be sped up?
A device that sprays the fat during melting speeds up the process several times. To order, we fit an agitator for the melt at the bottom of the tank.
How much does a fat melter cost?
Prices start from €3,400. The final price depends on volume, heating and options. We will prepare a quotation within one working day.
